KEY BENEFITS

>Protect capacitor banks in a variety of configurations with sensitive current and voltage balance protection functions

>Adaptive compensation techniques truly compensate for the inherent bank unbalance, providing sensitive protection

>Custom programmable logics for advanced shunt capacitor bank controls

>Flexible automatic voltage regulation of shunt capacitor banks along with control supervision

>Three independent fiber or copper Ethernet ports for simultaneous/ dedicated network connections with 1 microsecond time synchronization via LAN with IEEE® 1588 support

>Reduced relay-to-relay wiring and associated installation costs through high-speed inter-relay communications

>Embedded IEC 61850® protocol

>Increase network availability by reducing failover time to zero through IEC 62439-3 “PRP” support

>CyberSentry™ provides high-end cyber security aligned to industry standards and services (NERC® CIP, AAA, Radius, RBAC, Syslog)

>Complete IEC® 61850 Process Bus solution provides resource optimization and minimizes total P&C life cycle costs

APPLICATIONS

>Protection, control, monitoring and automation of shunt capacitor banks at different voltage levels

>Suitable for protecting multiple capacitor banks

>Sensitive protection for grounded and ungrounded single and parallel capacitor banks and banks with taps, for a variety of capacitor bank configurations

>Capacitor bank-based automatic voltage regulator (AVR) and capacitor control supervision
